True 3000W pure sine wave inverter featuring 3000W PV input, 100A MPPT charge controller, and 24V battery architecture for homes.
The Crown Micro Xavier 3KW (Model: X-3KW-PF1) is engineered to power complete mid-sized household circuits, small retail shops, and decentralized office branches. Delivering 3000W continuous output power with a unity power factor (PF 1.0) and 6000VA surge capacity, it handles high-inrush inductive motor loads effortlessly. The system incorporates a 100A MPPT solar charge controller paired with a 450VDC maximum open-circuit PV input stage. Its wide 60VDC to 400VDC operational window allows technicians to construct high-voltage series PV strings that start generating earlier at dawn and continue charging later into dusk.
Zener Authenticity Promise: All sitemarks, models, and technical statistics are registered with the factory and verified in our physical laboratory before sale.
When pairing with 550W panels, configure 6 panels as a single 6S string to achieve ~300VDC operating voltage, minimizing thermal loss.
Always balance the voltages of the two 12V batteries before connecting them in series to prevent premature cell failure.
Set the utility charging current to 20A–30A if using 200Ah lead-acid batteries to prevent overheating during national grid recovery.
Leave at least 20cm of clearance on all four sides of the chassis to permit unimpeded intake and exhaust airflow.
Yes, the Xavier 3KW easily starts and runs up to a 0.75 HP standard water pump or a 1.0 HP inverter pump due to its 6000VA surge capacity.
You can connect up to 3000W of solar panels, which matches approximately 5 to 6 units of 550W monocrystalline panels wired in series.
Yes, if battery backup is needed, it requires a 24VDC bank (two 12V batteries wired in series or one 24V/25.6V lithium battery module).
Yes, the Xavier 3KW supports battery-less operation, using solar PV directly to power your home during the day when sunlight meets demand.
The transfer time is 10ms in computer mode and 20ms in appliance mode, ensuring desktop computers and monitors stay powered without rebooting.
